TP-LINK AX11000
AX11000 Next-Gen Tri-Band Gaming Router
1.0-T_large.jpg)
1.0-F-USB_large.jpg)
1.0-B_large.jpg)
1.0-box.jpg)
Overview:
AX11000 Next-Gen Tri-Band Gaming Router
Archer AX11000
- The Fastest Gaming Router - AX11000 speed machine that delivers Wi-Fi Speeds Over 10 Gbps: 4804 Mbps (5 GHz Gaming) + 4804 Mbps (5 GHz) + 1148 Mbps (2.4 GHz)
- Game Accelerator - Detect and optimize gaming streams, to ensure your gaming stays immersive
- Game Protector - Keep your accounts and documents safe with Homecare™ security system powered by Trend Micro™.
- Game Statistics - Real-time latency, game duration and network resource allocation in a glance with fine-tuned UI.
- Ultra Connectivity - 2.5 Gbps WAN port and eight Gigabit LAN ports, 2 USB 3.0 in Type A and Type C provide extensive connectivity.
- Powerful Processing - 1.8 GHz Quad-Core CPU and 3 coprocessors ensure your network performance always at peak run.
- Highly Efficient - OFDMA increases the avg. throughput and reduces the lag.
- Easy and Smart - Link to your router via Bluetooth and set it up in minutes with the powerful Tether app.
Features:
ENTER THE 10 Gbps WI-FI ERA
Faster speed the router is, less congestion for gaming rigs. Armed with Wi-Fi 6, Archer AX11000 becomes the next-level speed machine that offers astonishing Wi-Fi speeds up to 10756 Mbps with an extended range.
LIGHTNING ATTACK TO DEFEAT LATENCY
More connected devices shall bring more fun rather than dragging the performance. Revolutionary OFDMA is introduced to improve average throughput by 4× and cut the latency. Take advantage of incredibly low latency to demolish your enemies, with your team crew together.
CRUSH THE LAG WIN THE GAME
GAME ACCELERATOR automatically detects and optimizes gaming streams, to ensure your gaming stays immersive, and keep your network as fast as your reaction speed.
KNOW YOUR NETWORK
GAME STATISTICS shows the real-time latency, game duration and system utilization at a glance in a refreshed dashboard with fine-tuned UI elements, puts total control at your fingertips.
KEEP ALL ELEMENTS SECURITY
GAME PROTECTOR keeps your accounts and system safe. This enhanced HomeCare™ security system is powered by Trend Micro™, delivering comprehensive antivirus protection that ensures you’re total security while gaming online.
GAME ON THE FAST LANE
GAMING BAND - a dedicated gaming band for your game rigs, makes your online games and your families' Netflix 4K streaming no more competitor. DFS expands available channel automatically, get on the more vacant lane and boost the game.
BATTLE-TESTED HARDWARE
Equipped with 1.8 GHz Quad-Core CPU and 1 GB of RAM to handle huge throughput and crush the lag. Link Aggregation and USB 3.0 type C and type A ports ensure virtually any device can connect to your home network.
Specifications:
| HARDWARE FEATURES | |
|---|---|
| Memory | 1 GB RAM and 512 MB Flash |
| Interface | 8 1G/100M/10M LAN Ports, 1 2.5G/1G/100M WAN Port 1 USB-A 3.0 Port + 1 USB-C 3.0 Port |
| Button | Wi-Fi On/Off Button, Reset Button, WPS Button, Power On/Off Button, LED on/off Button |
| External Power Supply | 12V/5A |
| Dimensions ( W x D x H ) | 11.3 × 11.3 × 7.2 in. (288 × 288 × 184mm) |
| Antenna | 8 High-Performance External Antennas |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | 5 GHz: 4804 Mbps(802.11ax) 5 GHz: 4804 Mbps(802.11ax) 2.4 GHz: 1148 Mbps(802.11ax) compatible with 802.11a/b/g/n/ac Wi-Fi standards |
| Reception Sensitivity | 5 GHz_1: 11a 6Mbps：-96dBm, 11a 54Mbps:-78dBm 11ac VHT20_MCS0:-95dBm, 11ac VHT20_MCS11:-65dBm 11ac VHT40_MCS0:-93dBm, 11ac VHT40_MCS11:-62dBm 11ac VHT80_MCS0:-90dBm, 11ac VHT80_MCS11:-59dBm 11ac VHT160_MCS0:-87dBm, 11ac VHT160_MCS11:-54dBm 11ax HE20_MCS0:-94dBm, 11ax HE20_MCS11:-62Bm 11ax HE40_MCS0:-91dBm, 11ax HE40_MCS11:-59dBm 11ax HE80_MCS0:-88dBm, 11ax HE80_MCS11:-57dBm 11ax HE160_MCS0:-84dBm, 11ax HE160_MCS11:-54dBm 5 GHz_2: 11a 6Mbps：-96dBm, 11a 54Mbps:-78dBm 11ac VHT20_MCS0:-95dBm, 11ac VHT20_MCS11:-65dBm 11ac VHT40_MCS0:-93dBm, 11ac VHT40_MCS11:-62dBm 11ac VHT80_MCS0:-90dBm, 11ac VHT80_MCS11:-59dBm 11ac VHT160_MCS0:-87dBm, 11ac VHT160_MCS11:-54dBm 11ax HE20_MCS0:-94dBm, 11ax HE20_MCS11:-62Bm 11ax HE40_MCS0:-91dBm, 11ax HE40_MCS11:-59dBm 11ax HE80_MCS0:-88dBm, 11ax HE80_MCS11:-57dBm 11ax HE160_MCS0:-84dBm, 11ax HE160_MCS11:-54dBm 2.4 GHz： 11g 6Mbps：-97dBm, 11a 54Mbps:-79dBm 11n HT20_MCS0:-97dBm, 11n HT20_MCS7:-78dBm 11n HT40_MCS0:-95dBm, 11n HT40_MCS7:-75dBm 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-67dBm 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-64dBm 11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-64dBm 11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-61dBm |
| Wireless Functions | Enable/Disable Wireless Radio, Guest network, DFS, MU-MIMIO, OFDMA |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| Transmission Power | CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.35GHz); <30dBm(5.47GHz~5.725GHz) FCC: <30dBm(2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz), <24dBm(5.25GHz-5.35GHz & 5.47GHz-5.725 GHz) |
| Guest Network | 2.4 GHz guest network0 × 1, 5 GHz guest network × 1 |
| SOFTWARE FEATURES | |
|---|---|
| Quality of Service | Advanced Gaming Qos powered by TrendMicro |
| WAN Type | Dynamic IP/Static IP/PPPoE/ PPTP(Dual Access)/L2TP(Dual Access) |
| Management | Advanced Parental control powered by TrendMicro, Local Management, Remote Management |
| DHCP | Server, DHCP Client List, Address Reservation |
| Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | DynDns, NO-IP, TP-Link |
| VPN | PPTP, OpenVPN |
| OTHERS | |
|---|---|
| Certification | FCC, CE, RoHS |
| Package Contents | Wireless Router Archer AX11000 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
| System Requirements | Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Cable or DSL Modem Subscription with an internet service provider (for internet access) |
| Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Documentation:
Download the TP-LINK AX11000 Next-Gen Tri-Band Gaming Router Datasheet (PDF).
